| General Technical Parameters | |||
| Overall Dimension | 7200*2400*2800 (mm) | ||
| Gross Vehicle Weight | 12360kg | ||
| Chassis Specification | |||
| Chassis Brand | ISUZU NKR Fuel Oil Delivery truck | ||
| Drive model | 4*2 | ||
| Cabin | Single row , Cab reversi ble, Left-hand Drive , with air condition. | ||
| Number of Passengers | 2. | ||
| Engine | Model | 120HP, with ABS. | |
| Power | 88KW/120HP | ||
| Emission standard | EURO 4 | ||
| Fuel type | Diesel | ||
| Gearbox | ISUZU, 5 Forwards & 1Reverse, manual operation, with power steering. | ||
| Brake System | Oil break, with vacuum booster pump. | ||
| Wheel Base | 3360mm | ||
| Front/Rear Axle Loading | 2500/4800 (Kg) | ||
| Overhang | Mechanical Suspension, | ||
| Tire | 650-16, steel wire tire, 6pc with 1 spare tire. | ||
| Max Driving Speed | 90 km/h | ||
| Upperstructure Specification | |||
| Fuel Tank | Tank Material | Q235B Carbon Steel (Stainless Steel and Aluminum Alloy can be choosed) | |
| Effective Volume | 5CBM | ||
| Medium Type | Fuel(Gasoline, Diesel, etc.) | ||
| Tank Thickness | 4mm | ||
| Compartment | 2 compartments, 2000 liters for each. (optional configuration) | ||
| Manhole cover | 2 units, with breath valves. | ||
| Emergency cut-off valve | 2 unit. | ||
| Discharging valve | 2 unit. | ||
| Lifting Ladder | 2 units. | ||
| Color | According to customer’s requirements. | ||
| Dispenser System | 1, Dispenser machine; | ||
| 2, Refueling retractable rubber hose reel and filling gun, 2 units; | |||
| 3. Pump. | |||
