ISUZU 600P 8000 liter hook arm garbage truck Product Description:
ISUZU 600P 8000 liter hook arm garbage truck Chassis configuration: 600P single-row driving cab, luxurious interior, Isuzu 120 horsepower engine, Isuzu five-speed gearbox, 3360mm wheelbase, 7.00 steel tires, ABS, dynamic rotation, 4T rear axle, air brake
ISUZU 600P 8000 liter hook arm garbage truck Upper assembly road: the volume of the car body is 8 cubic meters, which is made of carbon steel plate, the interior is made of anti-rust, hydraulic pump, multi-way valve, the car can be unloaded, the cab can be operated, and other factories are standard. A set of pull arm hook loading system is adopted, and the pull arm hook swings through the expansion and contraction of the oil cylinder to complete the hook loading, hook unloading and unloading of the sealed garbage bin.
ISUZU 600P 8000 liter hook arm garbage truck Specifications:
| Condition | New condition/Left hand drive/Right hand drive/4×2 | ||
| Main details | Wheelbase(mm) | 3300mm/3360mm/3400mm | |
| Front/Rear Axle loading(kg) | 2500/4500 | ||
| Rear axle ratio | 5.375(6.142) | ||
| Wheel track (front/rear) (mm) | 1440/1425 | ||
| Front/Rear overhang(mm) | 1110/1488 | ||
| Min. Ground Clearance | 190 | ||
| Approach/Departure angle(°) | 20.5/17 ° | ||
| Max. driving speed(km/h) | 100 | ||
| Battery | 12V*2 ; 100Ah*2 | ||
| Alternator | 14V 60A | ||
| Starter | 12V 2.8kw | ||
| Clutch | Dry single plate | ||
| Brakes | Hydraulic brake | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 6 pcs with one spare tire | |
| Specifications | 6.50-16 | ||
| Oil tank | Fuel tank material | Steel | |
| Fuel tank capacity (L) | 100 | ||
| Transmission | Manual type, 5 Forwards and 1 reverse | ||
| Cab | It can accommodate three people. With Air Conditioner | ||
| Engine | Brand | Optional | |
| Model | Optional | ||
| Fuel type | Diesel | ||
| Emission standard | Euro 1/Euro 2/Euro 3/Euro 4/Euro 5 | ||
| Upper & Control System | |||
| Garbage box | Capacity(cbm) | 8.0cbm/10.0cbm | |
| Tank material | Q235 carbon steel | ||
| Side plate thickness(mm) | 3.0 mm | ||
| Bottom thickness(mm) | 4.0 mm | ||
| pulley wheel quantity(pcs) | 4 pcs | ||
| Control System | Control model | Hydraulic control | |
| Control panel | Close to Cabin | ||
ISUZU 600P 8000 liter hook arm garbage truck Working parameter:
| Box time | Less than 15 seconds | Roller material | Cast iron or forged steel |
| Unboxing time | Less than 15 seconds | Control method | Electronic control + manual |
| Dump time | Less than 10 seconds | Operating position | Cab + car side |
ISUZU 600P 8000 liter hook arm garbage truck New craft:
ISUZU 600P 8000 liter hook arm garbage truck Optional configuration:
ISUZU 600P 8000 liter hook arm garbage truck detailed images:
ISUZU 600P 8000 liter hook arm garbage truck Structure diagram：
ISUZU 600P 8000 liter hook arm garbage truck Detail drawing:
Customizable garbage truck models
