Foton 5 ton wrecker tow truck
Foton 5 ton wrecker tow truck Chassis configuration：
Adopt Foton Aoling chassis, new wide-body cab, single-row forward, axle car interior, Cummins 156 horsepower engine, 5-speed gearbox, wheelbase 3800mm, 6-ton rear axle, 7.50R16 original steel tire Factory abs and flats are stamped with die, with power steering, original air conditioner, cruise at fixed speed, clutch booster, and air brake.
Foton 5 ton wrecker tow truck Bodywork configuration：
The truck has a length of 5.6 meters and a width of 2.33 meters. The flat can use a new type of disposable stamping plate or 4 thick old pattern plates. The load capacity of the flat plate is 5 tons. 4 tons of tops, 4 tons of hydraulic winches, 25 meters of steel wire rope, double-sided linkage operation, pair of auxiliary wheel trolleys, pair of 7-character forks, one set of onboard tools, 4 straps, two work lights, with yellow long Row of LED electronic warning lights.
Foton 5 ton wrecker tow truck specification:
| Vehicle technical parameters | |||
| product name | Wrecker | Dimensions | 7.39×2.35×2.4 meters |
| Total quality | 8.28 meters | Curb quality | 5.33 tons |
| Tablet size | 5.6×2.33 meters | Flat thickness | 4 thick |
| Winding specifications | 4 tons | Tops | 4 tons |
| Chassis technical parameters | |||
| Chassis name | Foton | Chassis model | BJ1089VEJEA-F2 |
| Number of axes | 2 | Number of tires | 7 (including spare tire) |
| Wheelbase | 3.815 meters | Tire specifications | 7.50R16 |
| Gearbox | 5 files | Rear axle | 6 tons |
| Fuel type | Diesel | brake | Air brake |
| Emission standard | GB17691-2005 National V, GB3847-2005 | ||
| engine model | Engine manufacturer | Displacement (ml) | horsepower |
| ISF3.8s5154 | Beiqi Foton | 3760 | 156 |
| Basic upload configuration | |||
| Standard configuration | 4 tons of tops, 4 tons of winches, 25 meters of wire rope, a pair of auxiliary wheel trolleys, a pair of 7-character forks, a pair of square sleeves, 4 sets of straps, chain hooks, two work lights, yellow electronic engineering warning lights A set of tools on board. | ||
| Optional configuration | Imported parts, tow forks, tow fork seats, hand-washing boxes, LED long row of flashing warning lights, and full floor can be installed. | ||
Foton 5 ton wrecker tow truck Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
