Dongfeng 10000 liter to 15000liters fuel oil tanker trucks
Dongfeng 10000 liter to 15000liters fuel oil tanker trucks Lao Dongfeng 153 adopts Dongfeng old model 145 chassis remodeling, flat head forward tilting cab, tank volume 10 tons to 15 tons. The vehicle is equipped with: optional Yuchai 130 horsepower, Cummins 170/190 horsepower engine, 6/8 speed gearbox, 1000 tires, intercooled supercharged engine.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.
|
Fuel Tank Dongfeng ( 10,000-15000 Litres )
|
||
|
General
|
Vehicle Brand
|
CLW
|
|
Chassis Brand
|
Dongfeng
|
|
|
Overall Dimension
|
8600 * 2480 * 3180 mm
|
|
|
GVW / Kerb Weight
|
15,700 kg / 7,005 kg
|
|
|
Cab
|
Cab Capacity
|
3 persons allowed
|
|
Air Conditioner
|
Air conditioner is optional
|
|
|
Engine
|
Fuel Type
|
Diesel
|
|
Engine Brand
|
Cummins engine
|
|
|
Power
|
190 Ps (140 KW)
|
|
|
Displacement
|
5900 ml
|
|
|
Emission Standard
|
Euro III
|
|
|
Chassis
|
Drive Type
|
4X2, left or right hand drive
|
|
Transmission
|
8-speed front, 1 reverse
|
|
|
Wheelbase/No. of axle
|
4500 mm / 2
|
|
|
Tyre Specification
|
9.00-20
|
|
|
Tyre Number
|
6 tyres and 1 spare tyre
|
|
|
Max Speed
|
80 km/h
|
|
|
Paint
|
Metallic paint
|
|
|
Superstructure
|
Tank Capacity
|
12,000-15000 Litres ( About 3,160 gallons)
|
|
Tank Material
|
Carbon steel
|
|
|
Pump
|
Fuel pump equipped for overhead delivery
|
|
|
Suction Head
|
6 m
|
|
|
Hose
|
High quality, wire strengthened hose, with cooper wire, anti-static
|
|
|
All standard accessories: manhole, ladder, anti-static belt, anti-slip walkway, handrail, fire extinguisher, inlet, discharge, reflective stickers……..
|
||
|
Optional
|
** Tank material could be carbon steel, stainless steel, aluminum (aluminum tanker)…… ** It can be divided into many compartments. ** Imported mechnical pump Blackmer ** Imported electrical pump Fillrite…. ** Devices can be equipped: flow meter, fuel dispenser, hose reel & nozzle, level gauge…… ** Heat preservation & heating system could be added. ** Bottom loading system can be equipped. |
|
