Foton 5000liters fuel flow truck
Foton 5000liters fuel flow truck：5.2 cubic meters single tank with pump in and pump out, with large flow tanker, automatic hoisting reel and fuel gun, European standard tank mouth, emergency cut-off device, automatic shutdown when the speed is> 5KM, fire extinguisher, infusion tube, static electricity The belt is standard, fireproof cap, folding railing, rear ladder, made of carbon steel, built-in wave plate corrugated plate in the tank body, maintenance manhole.
Foton 5000liters fuel flow truck tank body is made of carbon steel, with a single compartment with a pump in and a pump out, and a tool box on the side of the co-pilot for the outlet, with a European standard tank port, an emergency cut-off device (subsea valve) under the oil port, oil and gas recovery device, Stable large-flow dispenser and 15-meter automatic hoisting reel with fuel gun, aluminum rolling shutter toolbox in front of the tank body (or hanging tank body side), 2 infusion tubes of equal length to the tank body, 2 fire extinguishers , Reflective strips, flammable liquid signs, static tape, and the rest are made in accordance with factory standards.
Outlet test report, medium gasoline. (Optional sub-bin, fuel dispenser brand, flow meter measurement,) fuel dispenser brands include (Zhengxing, Hengshan, Sanjin, Bellin, Burley, Jialijia, Changwen, Zhongsheng, Lanfeng, Aocheng Various brands) Flow meter has 30, 40, 50 brands have Hefei flow meter, Chongqing flow meter, Ningbo flow meter
| General Technical Parameters | |||
| Overall Dimension | 5990×1960×2400(mm) | ||
| Gross Vehicle Weight | 8500(Kg) | ||
| Curb Weight | 3365(Kg) | ||
| Chassis Specification | |||
| Chassis Brand | Forland | ||
| Drive model | 4*2 | ||
| Cabin | Forland D1695, Single, RHD, with air condition. | ||
| Number of Passengers | 2 | ||
| Engine | Model | BJ493ZLQ1/108HP, 4-stroke direct injection , 4-cylinder in-line, intercooled supercharging, withABS. | |
| Power | 80KW/108HP | ||
| Emission standard | EURO 2 | ||
| Displacement | 3707(ml) | ||
| Fuel type | Diesel | ||
| Gearbox | 4Forwards & 1Reverse, manual operation. With power steering. | ||
| Brake System | Oil break rotation | ||
| Wheel Base | 3360mm | ||
| Front/Rear Axle Loading | 2000/4000(Kg) | ||
| Tire | 7.00R16, 1PC including 1 spare tire | ||
| Max Driving Speed | 90(km/h) | ||
| Upperstructure Specification | ||
| Oil Tank | Effective Volume | 5CBM |
| Transport Oil Type | Fuel | |
| Tank Material | Q235, carbon steel( also can choose stainless steel,aluminum ) | |
| Tank Shape | Square Round | |
| Manhole | 1unit Euro Standard manhole, DN500mm | |
| Refueling System | 1. Oil pump;
2. Oil dispenser machine; 3. Hose reel with filling gun. |
|
| Others | Emergency cut-off valve, Lifting fence, electrostatic wire reel, ladder, GPS, etc. | |
| Options | Compartments, unloading valve, flow meter, API standard manhole, oil vapor recovery, anti-overflow probe. | |
