FAW 5000 liter fuel truck for sale
FAW 5000 liter fuel truck Bodywork configuration:
The announcement volume is 4.19 cubic meters, the actual volume is 5 cubic meters, and the full load is 4 tons of diesel. The single tank of the tank has a pump in and pump out, a large flow tanker, an automatic hoisting reel and a fuel gun, a European standard tank port, and an emergency cut-off device.
FAW 5000 liter fuel truck Chassis configuration:
Jiefanghu VN flat-top single-row cab, single-row can be turned forward, Weichai 110 horsepower engine, WP2.3Q110E50, 5 speed gearbox Wanliyang 5TS32, 130 punching and welding bridge (speed ratio 5.125, wheelbase 1475), 180 * 65 * 5 frame, 7.00R1612 level (semi-wire), 70L plastic fuel tank, front disc rear drum brake, Beidou + GPRS driving recorder, rear processor front, fixed speed cruise, with domestic ABS, exhaust spark extinguisher , Leaf spring 7/7 + 3, new style, air conditioning, speed limit 79KM / H, central control lock, electric doors and windows. Comes standard with dangerous goods overhead lights (reflected at night), fire helmets, safety notices, dangerous goods signs, flammable gas signs, orange reflective tape, reflective signs, etc., electrostatic tow zone.
FAW 5000 liter fuel truck Vehicle description:
The announcement volume is 4.19 cubic meters, the actual volume is 5 cubic meters, the full load is 4 tons of diesel, the single tank of the tank is equipped with a pump in and pump out, with a large flow tanker, automatic hoisting reel and fuel gun, European standard tank mouth, emergency cut-off device, speed > Automatically shut off when 5KM, fire extinguisher, infusion tube, static belt as standard, fireproof cap, folding railing, rear ladder, made of carbon steel, tank body built-in wave board corrugated board, maintenance manhole, tank body meets the requirements of the upper household, Issue tank inspection report.
| General Technical Parameters | ||||
| Overall Dimension | 5990x2050x2500 (mm) | Gross Vehicle Weight | 7360(kg) | |
| Curb Weight | 3765(kg) | Loading Weight | 3405(kg) | |
| Chassis Specification | ||||
| Chassis parameters | Chassis Brand | FAW | ||
| Cabin | Single, Left Hand Driving | |||
| Engine | Power | 110HP | ||
| Emission standard | EURO V | |||
| Displacement | 3.7L | |||
| Fuel type | Diesel | |||
| Gearbox | 5 Forward & 1 Reverse Gear | |||
| Front and Rear Axle load | 3.5T rear axle | |||
| Wheel Base | 3300(mm) | |||
| Overhang( Front/Rear) | 1040/1647(mm) | |||
| Angle(Approach/departure) | 16/14(°) | |||
| Brake System | Pneumatic | |||
| Steering Gear | Power Assistant | |||
| Tire | 7.00R16, 6 Pieces | |||
| Maximum speed | 80(km/h) | |||
| Superstructure | ||||
| Fuel Tanker | Tank Volume | 5,000 Liters / 5m3 | ||
| Tank Material | Q235B Carbon Steel | |||
| Tank Shape | Square Round | |||
| Transport oil type | Diesel/Petrol | |||
| Refueling system | Oil Pump | 1pc, Chinese famous brand | ||
| Oil dispenser | 1pc, Chinese famous brand, Digital Screen Display with Keyboard, Oil Filling Display in Liter, Price & Amount | |||
| Hose Reel with Filling Gun | 6 Meter (Length can be longer as per request), Corrosion Resistant | |||
| Equipment | Lifting fence, ladder, Manhole 1 Unit, Emergency cut-off valve 1 Unit | |||
| Optional API standard system | Anti-overflow probe Oil Vapor Recovery Syste |
|||
