Shacman 14ton 16ton crane lift truck
Shacman 14ton 16ton crane lift truck Adopt Delong new M3000 cab, Weichai 336 horsepower, Fast 12-speed gearbox, 7.5T front axle, 13T rear axle, wheelbase 2100 + 4575 + 1400mm, with air conditioning, ABS, 12.00R20 steel tire, 400L aluminum Alloy fuel tank, 1200 tires, standard cargo box can be made into 8.5 meters manual telescopic or hydraulic telescopic cargo box, the rear can be equipped with ladders, automatic unloading elevator, aerial work and other multi-function trucks.
Our company are professional manufacturer in truck area, guarantee all goods Brand-New and China-Origined.
1. Chassis Model: ISUZU,JAC,JMC,IVECO,Dongfeng,FAW,Foton,HOWO,North Benz and etc.
2. Engine Model:Cummins,Yuchai,Weichai,Xichai,Sinotruk and etc.
3. Drive Model: 4×2,4×4, 6×2,6×4,6×6, 8×4, and three axis crane semi-tailer
4. Crane rotation angle: 360° with hydraulic systems straight /folding boom crane max loading weight:2T,3.2T,4T,5T,6.3T,8T,10T,12T,14T,16T,20T, 30T, 60T, 150T,Two-arm, three-arm and four-arm are optional.
5. Cargo box’s length:3-13m.Widely used in oil fields, weighing and inspection, telecommunications, power, factories, cement board factories, etc.
Shacman 14ton 16ton crane lift truck specification:
| Shacman 14ton 16ton crane lift truck | ||
| # | Descriptions | Specifications and types |
| General
|
Truck Brand | Chengliwei (our brand) |
| Chassis Brand | Shacman | |
| Approx. Dimension | 12000*2500*3910 mm | |
| GVW./Kerb Wt. | 31000/14700kg | |
| Cab
|
Cab Capacity | 3 persons’ seat |
| Air Conditioner | Air Conditioner is optional | |
| Chassis
|
Drive Type | 8X4,LHD or RHD |
| Fuel Type | Diesel | |
| Engine Make & Model | Weichai engine | |
| Power | 310hp | |
| Emission Standard | EURO II or Euro III or Euro V or Euro IV | |
| Brake | Air Brake | |
| Wheelbase/No.of axle | 1940+3910+1350 mm / 4 | |
| Tyre Specfication | 11.00-20,11.00R20,12R22.5 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 80 km/h | |
| Paint | Automative metallic paint | |
| Cargo box | Cargo body dimension | 8000*2300*800 mm |
| Crane
|
Max Lifting Capacity | 14000kg/16000kg /20000 kg /25000kg |
| Installation Space | 550-850mm | |
| Structure& Function | Telescopic/Articulated boom crane loading weight:2T,3.2T,4T,5T,
6.3T,8T,10T,12T,14T,16T,20T 25T or others Truck Cargo length: 3m-13m. Crane Brand optional: ZOOMLION, SMJ, SANY or others. Crane Installation Site: Rear or Middle part |
|
Shacman 14ton 16ton crane lift truck Working parameter:
