products details:
1. Optional chassis brand of portable water truck: Dongfeng, Isuzu, Sinotruk, FOTON/Forland, Faw, Shacaman, etc.
2.Tank body is automatically welded by the national standard high-quality steel plate, which can be self-absorbed and added with water + fire hydrant with water + tank top with water.
3.Pipeline adopts large-diameter seamless steel pipe + large-diameter ball valve, with large flow and long range, 2 front hedges, 2 rear sprinklers for dust reduction, and 2 side spray irrigation.
4. Rear large platform is equipped with a green water cannon with a range of 28 meters and can be rotated in all directions. It can be continuously adjusted to straight, heavy rain, light rain, drizzle, and fog.
Working parameter:
| Front nozzle | 15 meters hedge, optional duckbill forward | Tank material | Carbon steel Q345/stainless steel 304 |
| Rear sprinkler | Fan-shaped sprinkler, more than 20 square | Thickness of tank | 4-6 mm |
| Car side nozzle | Sprinkler water, more than 6 meters | Tank shape | Square, square, oval |
| Green anti-aircraft gun | Water column 28 meters, adjustable large, medium and light rain | In-tank treatment | Standard anti-rust coating, can be used for anti-acid alkali polyurea epoxy treatment |
| Water pump brand | International well-known brand pump | Water way | Self-priming water, fire water injection, tank top water injection |
| Optional configuration | Cab electrical control, cab display cursor level gauge, sprayer, detachable snow shovel and snow roll device, front guardrail cleaning device | ||
ISUZU 700P 10000l to 15000l water bowser truck Specification:
|
Specification of isuzu drinking water tanker truck
|
|||
| Item | Specification | Item | Specification |
|
General
|
|||
| Truck Name | tanker truck | Overall Dimension (mm) | 7000×2200×2650 |
| Truck Brand | Gross / Curb Weight (kg) | 7300/3360 | |
| Truck Model | SZD5070GSSQ5 | Rated Loading Weight(kg) | 3810 |
| Cab | Cab Capacity | 2 | |
| Approach / Departure Angle (°) | 22/15 | Front / Rear Overhang (mm) | 1015/1620 |
| Front / Rear Axle Load (kg) | 2580/4720 | Wheelbase (mm) | 3360 |
| Number of Axles | 2 | Max. Speed (km/h) | 110 |
| Quantity of Tyre | 6 | Tyre Model | 7.00-16 14PR,7.00R16 14PR |
| Front Wheel Tread (mm) | 1504 | Rear Wheel Tread (mm) | 1425 |
| Leaf Spring | 8/6+5 | Traction System | steering wheel |
|
Chassis
|
|||
| Chassis Brand | ISUZU | Chassis Model | QL1070A5HAY |
| Type of Fuel | diesel | Emission Standard | euro 3 |
|
Engine (Motor)
|
|||
| Model | Displacement (ml) | Max. Power (KW/hp) | Brand |
| 4KH1CN5HS | 2999 | 96/130 | ISUZU |
|
Truck Body
|
|||
| Tank Capacity (L) | 4000 | Tank Material | Food grade stainless steel |
|
Painting
|
Optional | ||
water truck New craft:
Optional configuration:
water spray truck Inspection Training:
—- SGS, BV, COTECNA, CE certification.
—- Local engineer training support.
Free Parts:
— Free parts for 12 months.
—- Supply of original parts.
—- DHL serves 7 days worldwide.
sprinkler truck Factory Advantage:
— 16 years of design and export experience.
—- 100% customized trucks.
—- Quick delivery guarantee.
Export Documents:
—- Serving more than 80 countries and regions.
—- Professional guidance on import documents.
—- CO, FORM E, FORM P, pre-implantation inspection …
water Spray truck Shipping:
—- Maximize your shipping costs.
—- Professional guidance on import documents.
—- Safe, fast and timely
Bulk order case:
—- Fast shipping to all parts of the world.
—- The truck color and logo can be customized.
