Dongfeng 8 ton towing wrecker trucks
Dongfeng 8 ton towing wrecker trucks Chassis：
Adopt Dongfeng Dolka D7 series chassis, wide-body single-row reversible cab, Chaochai 120 horsepower diesel engine, 5-speed gearbox, wheelbase 3800mm, 3 tons front axle, 5 tons rear axle, 7.50 tires, original abs With direction assistance, clutch assistance, and air brake.
Dongfeng 8 ton towing wrecker trucks Bodywork：
5 tons of conjoined bodywork, equipped with 4 tons of hydraulic winch, imported hydraulic system, double-sided linkage operation, 25 meters of steel wire rope, one set of tools, 4 straps, 3 rear working lights, 1 set of auxiliary lights, auxiliary 1 set of trachea assembly with 1 yellow long row of police lights.
Dongfeng 8 ton towing wrecker trucks specification:
|
Vehicle technical parameters
|
|||
|
product name
|
Dongfeng duolika towing trucks 10 tons and rotator tow truck price
|
Dimensions
|
6.5 x2.25×2.5 meters
|
|
Total mass
|
6.495 tons
|
Curb quality
|
5.1 tons
|
|
Hoisting specification
|
5 tons
|
Tops
|
3 tons
|
|
Chassis technical parameters
|
|||
|
Chassis name
|
Jiangling
|
Chassis model
|
EQ1080TG25
|
|
Number of axes
|
2
|
Number of tires
|
7 (including spare tire)
|
|
Wheelbase
|
3.36 meters
|
Tire specifications
|
7.00R16
|
|
Gearbox
|
5 files
|
Rear axle
|
2.5 tons
|
|
Fuel type
|
Diesel
|
brake
|
Oil brake
|
|
Emission basis
|
GB17691-2005 country V, GB3847-2005
|
||
|
engine model
|
Engine manufacturer
|
Displacement (ml)
|
horsepower
|
|
CY4110
|
Chao chai
|
3771
|
120 horsepower
|
|
Top basic configuration
|
|||
|
The standard configuration
|
3 tons of tops, 3 tons of winches, imported hydraulic system, 25 meters of steel wire rope, a pair of auxiliary wheel trolleys, a pair of 7-fork, a pair of square sleeves, 4 sets of straps, chain hooks, two work lights, yellow electronics Engineering warning lights, a set of vehicle tools.
|
||
|
Optional configuration
|
Can be equipped with automatic clamping device, fork, fork, LED long row flashing lights
|
||
Dongfeng 8 ton towing wrecker trucks Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
