8X4 HOWO 25m3 to 30m3 mobile fresh milk holding tank truck Adopt 8×4 Howo cab, Sinotruk 370 horsepower engine, 10 speed gearbox. The volume of the tank is 25-30 cubic meters, and the internal size of the tank is 9000×2150×1530 (mm). The standard sub-bin is Three warehouse, and each warehouse has a self-flow outlet.
milk tanker truck advantages:
1. Tank material: stainless steel 304-2B, food grade material. All pipes and valves are made of stainless steel.
2. 80mm Polyurethane foam to keep temperature to prevent milk spoilage.
3. Equipped with CIP cleaning device to clear the inner side of tank to keep it clean.
4. Support transportation medium: Milk, drinking water, cooking oil , beer , maltose, maltose, ice cream
5. Optional compartments, installation of pumps, flowmeters, etc.
Tank manufacturing standards：
The tank body is composed of an inner tank, a heat preservation layer, and a heat preservation layer protection layer:
1. The liner is made of 3mm thick 304 food grade stainless steel, seamlessly welded and finely polished. The tank is equipped with a wave structure anti-wave plate, which has strong impact resistance.
2. The PIC automatic cleaning system is used in the tank, and the cleaning device rotates 360 degrees in all directions. It can clean any dead corners in the tank to achieve the best cleaning effect. A special heat preservation milk storage tank. Insulation performance, hygiene standards can reach the domestic advanced level.
3. The tank insulation layer uses 8cm thick polyurethane, the density reaches 32~35 kg/cubic, to ensure that the temperature rise and fall within 24 hours during transportation is less than or equal to 1 degree. Ensure the quality of fresh milk during transportation.
4. The outer layer of the tank belongs to the protective layer of the thermal insulation layer, which is made of stainless steel plate, which is light-weight, light weight and good strength.
5. There is a vent valve on the top of the tank to automatically adjust the opening to reduce the evaporation loss of the liquid and prevent the tank from deforming when positive and negative pressures are generated in the tank.
6. It can transport and transport fresh milk, liquid food, purified water, edible oil and other media at the same time through sub-bins.
8X4 HOWO 25m3 to 30m3 mobile fresh milk holding tank truck Specification:
|
specification of milk Tank Truck
|
||
| Truck Model | ZZ1257N4647C LHD | |
| Dimension (Lx W xH)(unloaded)(mm) | 10350x2496x3048 | |
| Tank volume | 20m3 with 2 compartments | |
| Overhang(front/rear) (mm) | 1500/2900, | |
| Wheel base (mm) | 4600+1400 | |
| Max speed(km/h | 102 | |
| Curb weight(kg) | 11360 | |
| Loading Weight(kg) | 30000 | |
| Fuel tanker capacity(L) | 300L with locking fuel cap | |
| Power take off | HW70 | |
|
Engine |
Model | WD615. water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection |
| Fuel type | Diesel | |
| Horse Power,max(kw/rpm) | 336HP, | |
| Emission | EURO2 | |
| Transmission | Model | HW13710,10 forward&2 reverse |
| Brake system | Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Steering system | Model | ZF8098 hydraulic steering with power assistance |
| Front axle | HF7 | |
| Rear axle | ST16 | |
| Tyre | 295/80R22.5 11 pieces(1 spare) | |
| Electrical system | Battery | 2X12V/165Ah |
| Alternator | 28V-1500kw | |
| Starter | 7.5Kw/24V | |
| Cab | HW76 cab(one bunk, with air conditioner) | |
Milk tank truck detailed picture:
