6×4 HOWO 20ton to 25ton heavy duty wrecker truck
6×4 HOWO 20ton to 25ton heavy duty wrecker truck Chassis：
It adopts Sinotruk Howo chassis, row and half cab, Howo 338 horsepower engine, ten-speed gearbox, wheelbase 5825 + 1350mm, 12.00R20 original steel tire, air brake, original abs.
6×4 HOWO 20ton to 25ton heavy duty wrecker truck Bodywork：
20 ton joint bodywork, two-section hexagonal boom, three-section support arm, split carriage, imported hydraulic system, double-sided linkage operation device, and front bumper equipped with counterweights.
Two 10 ton electro-hydraulic winches, 45-meter steel wire rope, 18mm in diameter, with 4 sets of steel forks, 1 set of trailers, 1 set of steel plate lugs, 1 set of tire holding devices, 1 set of tools on board, auxiliary light assembly 1 set, 1 set of auxiliary trachea assembly, 1 yellow long row LED engineering warning light.
6×4 HOWO 20ton to 25ton heavy duty wrecker truck specification:
| Vehicle technical parameters | |||
| product name | Wrecker | Dimensions | 10.475×2.5×3.8 meters |
| Total quality | 25 tons | Curb quality | 21 tons |
| Winding specifications | 20 tons | Tops | 20 tons |
| Chassis technical parameters | |||
| Chassis name | Sinotruk Howo | Chassis model | ZZ1257N5847E1 |
| Number of axes | 3 | Number of tires | 11 (including spare tire) |
| Wheelbase | 5.825 + 1.35 | Tire specifications | 12.00R20 |
| Gearbox | 10 files | Rear axle | 15 tons |
| Fuel type | Diesel | brake | Air brake |
| Emission standard | GB17691-2005 National V, GB3847-2005 | ||
| engine model | Engine manufacturer | Displacement (ml) | horsepower |
| D10.34-50
D10.38-50 |
Heavy Group
Dongfeng Cummins |
9726
9726 |
338 horsepower
375 horsepower |
| Basic upload configuration | |||
| Standard configuration | 20-ton conjoined bodywork, equipped with winch 10 tons x 2 hydraulic winch, 45-meter steel wire rope, 4 sets of steel forks, one set of trailers, one set of steel plate lugs, one set of tire protection devices, one set of tools on board, auxiliary lights One set of assembly, one set of auxiliary trachea assembly, and one set of yellow long-row engineering warning lights. | ||
6×4 HOWO 20ton to 25ton heavy duty wrecker truck Advantage:
The loading surface of the platform is formed by stamping die once. The endurance is strong and the shape is not deformed. The plate surface is smoother, the structure is more professional and the strength is higher. The hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
It integrates multiple functions such as lifting, carrying, dragging, pulling and so on. The hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
