5000liters to 15000liters fuel oil semi trailer
5000liters to 15000liters fuel oil semi trailer Specification:
1. Tank material: we can provide carbon steel tanks, stainless steel tanks, manganese steel tanks, aluminum tanks, steel with plastic (or rubber) tanks and plastic tanks.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.
2. Good welding: tank body is adopted an advanced automatic vertical welding techniques and head arc butt welding technology, as well as the whole- steel forming a composite.
3. High safety: equip with active and passive emergency protection devices, to provide full closure remote manipulation of materials handing functions. Equip separators [Baffle] to prevent surging of liquid towards bulk head
4. Function: The tank body is suit for loading light fuel oil, heavy oil, sulfuric acid, hydrochloric acid, nitric acid, caustic soda hydrogen peroxide, alcohol, benzene, cooking oil and so on.
5. Oil punp: gear pump, self-absorption (centrifuge) pump, chemical pump, heavy, oil pump, stainless steel pump are optional.
6. Tank shape: shape of tank body can be designed to square round, round,Heat insulation device such as heating pipes, insulation.
7. Refueling machine: the refueling machine we use are tax controled oiling machine with accurate figure of volume, sum of money,etc.
8. Optional: reading meter for outlet and inlet,self-discharge valve at rail or side of tank body, compartment quantity according to the demand.
|
5cbm 2-Axle Full fuel Tank Trailer with drawbar trailer(OTHER SIZE OPTIONAL)
Overall Diameters
|
|||
| Weight | |||
| Loading Capacity | 5T | ||
| Axle number | 2 | ||
| Axle specs. | Fuwa Brand | ||
| Suspension | America type mechanical Suspension | ||
| Wheel | 11:00 R20 | ||
| Turntable | Diameter is 1100mm | ||
| Traction hook | DN50 | ||
| Traction bar | Length is 1.4m | ||
| Dimensions(LxWxH) | 8500×2500×1500mm, (working length is 7m) | ||
| Steel Spring | 10/10 pieces per axles | ||
| Tire: | |||
| Number of rim | 8 | ||
| Spare Tire Carriers | 1/piece | ||
| Frame: (specs. and materials) | |||
| The material of Main beam |
The height of the beam is420mm,upper plate is 12mm*140,down plate is 12*140mm,middle plate is 6mm(strictly).made of Q345 | ||
| Platform plate | 3mm Diamond Plate | ||
| Brake: | VABCO VALVE | ||
| Brake | Kemi Brand of China | ||
| Brake Chamber | TWO double and two single chamber( TKL brand ) | ||
| ABS system | with | ||
| Type | Model | Payload (Litre) | Usage |
| Oil tank semi trailer | CLW0301GYY | 35000L~65000L | Gasoline,diesel oil,kerosene,jet fuel |
| Bitumen/asphalt tank trailer | CLW0201GLY | 35000L~55000L | Tar,Bitumen ,asphalt |
| Chemical liquid tank trailer | CLW0301GHY | 35000L~65000L | Acids ,Alkalies,Hydrogen peroxide,ammonium hydroxide |
| Flammable liquid tank trailer | CLW0301GRY | 35000L~65000L | Crude oil, pentane, petroleum ether,alcohol |
| Liquid food tank trailer | CLW0301GYS | 35000L~65000L | Edible oil,beer,milk,water,juice,ice cream,sugar water |
